020 System is part of the Ruby® Embolization Platform. At .020″, it offers a large primary diameter designed for vessel sacrifice and aneurysm embolization. It is indicated for arterial and venous embolization in the peripheral vasculature.

    • A primary diameter of .020″
    • Compatible with the LANTERN® Microcatheter
    • Available in Ruby Coil, POD®, and Packing Coil
    • Available in sizes up to 40 mm with Ruby Coil and lengths up to 60 cm
    • True mechanical occlusion technology (no fibers or hydrogel)
    • Up to 2× more volume per coil than conventional .018″ systemsb

    a. 020 System includes the Ruby Coil System and POD System
    b. Compared to fibered coils, Azur™ CX 18, and Balt Prestige™ Plus

    • Compatible with standard .025″+ high-flow microcatheters
    "LP System" Text on Transparent Background "020 System" Text on Transparent Background "XL System" Text on Transparent Background
    Ruby Coil LP
    Packing Coil LP    		 Ruby Coil
    POD
    Packing Coil    		 Ruby Coil XL
    POD XL
    Packing Coil XL
    Diameter .0135" on Orange Circle Diameter .020" on Red Circle Diameter .030" on Red Circle
    .0165″+
    Low Profile
    Microcatheter Compatible    		 .025″+
    High-Flow
    Microcatheter Compatible    		 .035″+
    Diagnostic
    Catheter Compatible
    • Ruby Coil
      • Designed to frame in medium-to-large aneurysms and vessels (3–32 mm)
    • POD
      • Designed to anchor for high-flow vessels (3–14 mm)
    • Packing Coil
      • Designed to conform to the shape of any vessel for dense, controlled packing (5–60 cm lengths)

MRI Compatibility

Learn More

Related Cases

Angiogram of pulmonary arteriovenous malformation

Pre, Intra & Post

angiogram of embolization coils being deployed within the body

Pre, Intra & Post

angiogram of Embolization coils placed into a body

Pre, Intra & Post

Pulmonary AVM

Coils Used:
(1) 14 mm × 60 cm Ruby Standard
(1) 12 mm × 60 cm Ruby Standard
(1) 8 mm × 60 cm Ruby Soft

Dr. Justin McWilliams 
Ronald Reagan UCLA Medical Center, CA

angiogram of an embolization coil deployed in the body

Pre, Intra Post

angiogram of embolization coil being deployed in the body

Pre, Intra Post

angiogram of an embolization coil deployed in the body

Pre, Intra Post

Hypogastric/Internal Iliac Embolization

Coils Used:
(1) POD 4;
(1) 15 cm Packing Coil
(1) 30 cm Packing Coil
(1) 45 cm Packing Coil

Dr. Naiem Nassiri 
Yale University School of Medicine, CT
